BIOPHARMACEUTICAL WATER PURIFICATION
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-RO-3000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Export Standard and Wood Package |
| Delivery Time: | 35 days after receiving the deposit |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 Sets/Month |
|
Detail Information |
|||
| Conductivity: | 2--0.5 μs/cm | Recovery Rate: | >97% |
|---|---|---|---|
| RO Housing: | SS 304 316 8040 4040 | Connection: | Clamp ,Welding |
| Power Supply: | AC 220V / AC 380V / 415V±5% 50 HZ / 60HZ | Valve Control: | Pneumatic , Manual |
| RO Membrane: | High Temperature, Normal Temperature Type | ||
Product Description
Product Name: BIOPHARMACEUTICAL WATER PURIFICATION
PURIFIED WATER
Purified Water (PW) is sufficient for use as a diluent in the production of non-sterile products and for cleaning equipment. Pharmaceutical companies also use purified water as pretreatment in the preparation of Water for Injection (WFI) and pharmaceutical-grade pure steam production.
Some common uses for USP purified water generation systems include:
Making pill-form drugs: Purified water is used in the preparation of pill-form medications that are administered orally and absorbed in the human system.
Making drugs noninjectable drugs: Other non-parenteral drugs that use purified water during preparation include topical ointments, patches, suppositories and products administered through the ear, eye and nose.
Cleaning laboratory equipment: Purified water is the best solution for washing process equipment for non-parenteral product preparation and other product-contact containers. Purified water may also be used in the initial washing of components used in parenteral product manufacturing.
Pretreatment for water use: Biopharmaceutical companies also use purified water as pretreatment in systems in the preparation of WFI and pure steam production.
Common Process :
1. Single RO System :The raw water tank→the raw water pump→Multi-medium filter →Activated Carbon filter→Scale inhibitor device→1st safe filter→1st High Pressure Pump→1st RO Device→Pure water tank
2. Doubel Reverse Osmosis System:The raw water tank →the raw water pump→Quartz sand filter →Activated Carbon filter→Scale inhibitor→1st security filter→1st High Pressure Pump →1st REVERSE OSMOSIS System →1st RO Water tank→2nd HPP →2nd RO Device →Pure Water Tank
3. 1 st Reverse Osmosis system +EDI system:the raw water tank →the raw water pump→Quartz Sand Filter→Activated Carbon filter→Softener →1st security filter→1st HHP →1st RO Device→RO water tank →EDI booster pump →EDI device→Pure Water Tank
4. Double reverse osmosis system+EDI system:The raw water tank→the raw water pump→Quartz sand filter →Activated carbon filter→Softener→1st security filter→1st RO High pressure pump→1st RO Device→1st RO Water tank →2nd High Pressure Pump→2nd REVERSE OSMOSIS System →2nd RO Water tank→EDI booster pump →EDI System →Pure Water Tank .
Technical Parameter:
| Output Water Capacity | 0.5m3/h--50m3/h |
| TOC | ＜100PPB |
| Conductivity | ＜0.5μs/cm |
| Microorganism | ＜100 CFU/ml |
| Endotoxin | ＜0.25EU/ml |
| Nitrate | ＜0.06PPM |
| Heavy metal | ＜0.1 PPM |
FAQ:
1.Question: How to maintain the water treatment equipment ?
Answer : Purified Water Equipment can be remotely controlled , In case there is fault of software .
2.Question:How to treat hardware problem during the guarantee period ?
Answer : Directly contact with us , CHONGYANG Water is responsible for changing parts with free. The customer bear freight cost .
3.Question : How to deal with small problem during working day ?
Answer : By wechat ,whatapp on-line in time.
