SS304 SS316 Uv Purification Pharma Purified Water Filter System For Blood Goods
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-ROE-2000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 4999-10000 |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Sets/Month |
|
Detail Information |
|||
| Purpose: | Purified Water Production | Connection Type: | Clamp/Weld |
|---|---|---|---|
| Controls: | PLC/HMI | Documentation: | DQ/IQ/OQ/PQ |
| Raw Water Source: | Purified Water Production | Material: | 316L Stainless Steel |
| Sanitization: | CIP/SIP | Validation: | 21 CFR Part 11 |
| Highlight: | SS304 uv purification,SS316 uv purification System,SIP water filter system |
||
Product Description
Product Name : SS304 316 Material Pharma Purified Water System for Blood Goods & Injection
Purified water is widely used for preparation,solution and cleaning process in pharma industry. It has strict requirements for bacterial and pyrogen. Our PW/WFI system is totally designed according to GMP standard and customer's requirement, all joints using automatic orbital atgon-arc welding,whole system can realize fully automatic PLC control and sterilization. Over past decade, we have supply and design GMP or UPS standard pure water system for above 100 Pharma industries.
Pharmaceutical purified water system fetures:
Standard: GMP,UPS,YY0229
Parts material: SS304(connecting parts are SS316)
Control types: Automatic, semi-automatic, and manual
Bacteria: <100CFU/ml
Application: produce diversified blood goods, injection, biological bactericide and so on.
| Product Name | Function |
| Raw water tank | Storage raw water ,regulating the water intake,and precipitation of the impurities in the water. |
| Sand filter | it can remove sediment,impurity ,suspended objects and the other particles in water to reduce turbidity of water. |
| Carbon filter | The used of carbon adsorption principle that to absorb the different colors,odors,residual chlorine and so on . |
| Softener | The used of special resin absorb Ca &Mg ions in water ,then replace them ,that to reduce water hardness. |
| Security filter | Prevent impurity of big particles into Reverse Osmosis Membrane ,resulting in damage to membrane ,that can protect RO Membrane. |
| Reverse Osmosis | By Principle of Reverse Osmosis to achieve purpose of producing pure water. |
| Double Stage Pure Water Tank | Storage RO Water ,that provide pure water source for the latter system |
| PH Regulation System | By PH regulation to reomove CO2 from water to ensure quality of production water . |
| UV Sterilizer | Killing residual bacteria in water to ensure water quality |
| Nanofiltration Membrane | Remove bacteria that killed by UV and the other particles . |
| Ozone Sterilization | Used for cleaning purified water pipe and purified water tank. |
| Booster Pump of Purified Water | Used for transporting pure water for water points . |
FAQ:
1.Question: How to maintain the water treatment equipment ?
Answer : Purified Water Equipment can be remotely controlled , In case there is fault of software .
2.Question:How to treat hardware problem during the guarantee period ?
Answer : Directly contact with us , CHONGYANG Water is responsible for changing parts with free. The customer bear freight cost .
3.Question : How to deal with small problem during working day ?
Answer : By wechat ,whatapp on-line in time.
