Pharma Purified Water System RO Systems And EDI Chemical Cleans
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-ROE-2000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 4999-10000 |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Sets/Month |
|
Detail Information |
|||
| Application: | Pharma, Biological, Medical | Welding: | Track Welding |
|---|---|---|---|
| Controls: | PLC/HMI | Documentation: | DQ/IQ/OQ/PQ |
| Sterilization: | 70-85 Celsius Degrees Hot Water | Material: | 304 & 316L Stainless Steel |
| TOC Meter: | GE Brand, SUZE | Process: | Reverse Osmosis +EDI |
| Valve: | Diaphragm Valve | ||
| Highlight: | Reverse Osmosis Purified Water System,EDI Chemical Cleans Purified Water System,EDI Pharmaceutical Pure Water Systems |
||
Product Description
Product Name: Chemical cleans of RO systems and EDI For Purified Water System
1.Product profile :
In order to save comsuable cost,the purified water system will be added CIP System that clean RO Membrand by Chemical,NaOH and citric acid. That can reduce replacement frequency of RO Membrane .
2.Typical Preparation Process:
The raw water ---The raw water pump ---Multi-media Filter---Activated Carbon Filter---Automatical softener device---Safe Filter---the first stage HP Pump---the first RO Device---The middle water tank---the second HP Pump---the second RO Device ---Pure Water Tank-- Water Pump---UV --Microporous Membrane Filter---the used water point (New Technology)
The raw water ---The Raw Water Pump--Mutli-media filter----Activated Carbon filter---Softener Device----Safe Filter----The first stage HP pump---the first stage RO---the middle water tank---the booster pump---EDI Device---Pure water tank ----Water pump ---UV ---UF Membrane filter---used water point.(The latest Technology)
3.CHONGYAGN WATER Spec. & Type
|
Type |
Water Output(L/H) | Feed Water(M3/H) | Water Production Rate% | Desalination Rate% | Water Working Temperature °c |
| CY-PW-500 | ≥500 | 1.35-1.4 | ≥75% | 98% | 10-25 |
| CY-PW-1000 | ≥1000 | 2-2.2 | ≥75% | 98% | 10-25 |
| CY-PW-2000 | ≥2000 | 4-4.3 | ≥75% | 98% | 10-25 |
| CY-PW-3000 | ≥3000 | 5.3-5.8 | ≥75% | 98% | 10-25 |
| CY-PW-4000 | ≥4000 | 7-7.6 | ≥75% | 98% | 10-25 |
| CY-PW-6000 | ≥6000 | 10.6-11.5 | ≥75% | 98% | 10-25 |
| CY-PW-8000 | ≥8000 | 14.2-17 | ≥75% | 98% | 10-25 |
| CY-PW-10000 | ≥10000 | 17-19 | ≥75% | 98% | 10-25 |
Note : We can provide detailed scheme of design according to actual your requirement .
FAQ:
1. Questions :Is the circulating system important for Pharma Water System ?
Answer : Sure . Circulating system design is an important for purified water system .A one-way system is basically a "dead-leg " .
2. Questions : Can the purified water system be used for cosmetic industry ?
Answer : With improvement of living conditions, The high level cosmetic series need to pharma class water treatment system .
3.Questions: Do there need diaphragm valve on sampling water place ?
Answer:Sure .
