EDI WFI Pharma Water System Stainless Steel 304 316 Water Treatment System In Pharmaceutical Industry
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-ROE-2000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Sets/Month |
|
Detail Information |
|||
| Product Name: | Pharma Water System | Connection Type: | Clamp/Weld |
|---|---|---|---|
| Pipeline Passivate: | Available | Documentation: | DQ/IQ/OQ/PQ |
| Installation Rule: | 3D Rule | Material: | 316L Stainless Steel |
| Polished: | 0.8-0.6 Ra | Validation: | 21 CFR Part 11 |
| Factory Acceptance Test: | Available | Site Acceptance Test: | Available |
| Highlight: | EDI Pharma Water System,WFI Pharma Water System,2000L/H water treatment system in pharmaceutical industry |
||
Product Description
Product Name: Heat Exchanger EDI RO Purified Water System for pharmacy Fully Automatic
Technical Parameter:
Performance and technical parameters
TOC<100ppb;
Conductivity <2us/cm;
Microorganism <100CFU/ml;
Endotoxin <0.25EU/ml
Nitrate <0.06ppm Heavy metal <0.1ppm
Features of Pharmaceutical Water System
- Low and stable conductivity value can be reached.
- High efficiency of producing pure water ,which could reach 70% recovery.
- Each unit with a sample point ensures the inspection convenience.
- The pharmaceutical water system could be set into self circulating stand-by state within low-flux,which could have a shorter response time when restarted .
- Save energy.
- High manufacturing quality: all joints use automatic orbital argon-arc welding and conforming to the 3D standards.
- The equipment can drain completely .
- Module design and compact conformation.
- Perfect control system can guarantee the stable running of followed systems .
- The double softener design can keep the next equipment running continuously.
- Double pipe pure water supply,internal circulation for the purified water generator can be achieved .
- Fully automatic control and sterilization.
- Unique hygienic internal circulation design.
- Our pharmaceutical water system complies with requirements of FDA,EU-GMP,etc.
| Type | Water Output(L/H) | Feed Water(M3/H) | Water Production Rate% | Desalination Rate% | Water Working Temperature °c |
| CY-PW-500 | ≥500 | 1.35-1.4 | ≥75% | 98% | 10-25 |
| CY-PW-1000 | ≥1000 | 2-2.2 | ≥75% | 98% | 10-25 |
| CY-PW-2000 | ≥2000 | 4-4.3 | ≥75% | 98% | 10-25 |
| CY-PW-3000 | ≥3000 | 5.3-5.8 | ≥75% | 98% | 10-25 |
| CY-PW-4000 | ≥4000 | 7-7.6 | ≥75% | 98% | 10-25 |
| CY-PW-6000 | ≥6000 | 10.6-11.5 | ≥75% | 98% | 10-25 |
| CY-PW-8000 | ≥8000 | 14.2-17 | ≥75% | 98% | 10-25 |
| CY-PW-10000 | ≥10000 | 17-19 | ≥75% | 98% | 10-25 |
FAQ:
1. Questions :Is the circulating system important for Pharma Water System ?
Answer : Sure . Circulating system design is an important for purified water system .A one-way system is basically a "dead-leg " .
2. Questions : Can the purified water system be used for cosmetic industry ?
Answer : With improvement of living conditions, The high level cosmetic series need to pharma class water treatment system .
3.Questions: Do there need diaphragm valve on sampling water place ?
Answer:Sure .
