Pharma Water Generation System With EDI Polishing Unit
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO |
| Model Number: | CY-PWS-2000LPH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | USD 100--1000 |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Sets/Month |
|
Detail Information |
|||
| Capacity: | 250L/H–50000L/H | Conductivity: | ≤1.3 μS/cm |
|---|---|---|---|
| TOC: | ≤500 Ppb | Microbial Limit: | ≤100 CFU/ml |
| Recovery Rate: | ≥97% | RO Configuration: | Double Pass RO |
| EDI Module: | Optional | RO Membrane: | 4040 / 8040 |
| RO Housing: | SS304 / SS316L | System Material: | SS304 / SS316L |
| Piping Material: | SS316L Electropolished | Surface Finish: | Ra ≤0.6 μm |
| Connection: | Clamp / Welding | Sanitization Method: | Ozone / Hot Water / UV |
| UV Sterilizer: | 254nm UV | Control System: | PLC + HMI Touch Screen |
| Valve Control: | Pneumatic / Manual | Installation Type: | Modular Skid Mounted |
| Power Supply: | AC 220V / AC 380V / 415V±5% 50 HZ / 60HZ | Application: | Clean Utility Water Generation |
| Standards: | GMP / USP / FDA / WHO | Documentation: | FAT / SAT / IQ / OQ / PQ |
| Operation Mode: | Automatic / Manual | Temperature Type: | Normal Temperature / High Temperature |
| Cleaning System: | Automatic CIP Optional | ||
| Highlight: | Pressurized Loop Purified Water Distribution System,Loop Purified Water Distribution SystemISO,Purified Water System For Injection System |
||
Product Description
Pharma Water Generation System With EDI Polishing Unit
A pharma water generation system with EDI polishing unit is designed to produce high-purity process water for clean utility applications requiring stable conductivity control and continuous water quality performance.
The system is widely used in biotechnology, healthcare, laboratory, cosmetics, food processing, and electronics industries where hygienic engineering and low-conductivity water are essential.
What Is a Pharma Water Generation System With EDI Polishing Unit?
This system is an advanced purified water production solution that combines reverse osmosis technology with continuous electrodeionization for high-purity water generation.
EDI technology continuously removes dissolved ions without frequent chemical regeneration. This improves water quality stability, reduces operating costs, and minimizes maintenance requirements.
- Pretreatment system
- Reverse osmosis unit
- EDI polishing module
- UV sterilization system
- Sanitization module
- Sanitary storage tank
- Distribution circulation loop
- Online monitoring instruments
Technical Specifications
The system capacity, conductivity, tank material, RO configuration, and EDI module can be designed according to different clean utility requirements.
| Model | Capacity | RO Configuration | EDI Module | Conductivity | Tank Material | Application |
|---|---|---|---|---|---|---|
| CY-EDI-500 | 500 L/H | Single Pass RO | Standard EDI | ≤1.3 μS/cm | SS304 | Laboratory |
| CY-EDI-1000 | 1000 L/H | Double Pass RO | Enhanced EDI | ≤1.0 μS/cm | SS304 / SS316L | Healthcare |
| CY-EDI-2000 | 2000 L/H | Double Pass RO | Industrial EDI | ≤0.8 μS/cm | SS316L | Biotechnology |
| CY-EDI-5000 | 5000 L/H | Double Pass RO | High Efficiency EDI | ≤0.5 μS/cm | SS316L | Clean Utility |
| CY-EDI-10000 | 10000 L/H | Double Pass RO | High Capacity EDI | ≤0.5 μS/cm | SS316L | Industrial Process |
| CY-EDI-20000 | 20000 L/H | Multi-Stage RO | Customized EDI | ≤0.5 μS/cm | SS316L | Large Scale Production |
Features & Advantages
EDI Polishing Technology
Continuously removes ionic contaminants and improves conductivity stability.
Stable Water Quality
Integrated RO and EDI process supports reliable low-conductivity water generation.
Reduced Chemical Use
EDI technology reduces chemical regeneration and lowers maintenance requirements.
Hygienic Engineering
Sanitary piping, smooth surfaces, and circulation design improve system reliability.
PLC Automation
Automatic operation supports monitoring, alarms, data recording, and remote functions.
Loop Sanitization
Optional ozone, UV, and hot water systems help maintain microbial control.
Skid-Mounted Design
Compact modular structure supports easier installation and future expansion.
Energy Efficient
Optimized RO recovery and EDI efficiency help reduce operation cost.
Application Industries
Biotechnology
Used for fermentation systems, biological processing, and clean utility water generation.
Healthcare
Suitable for equipment cleaning, sterilization applications, and hygienic utility systems.
Laboratory
Provides stable purified water for analytical testing and scientific research environments.
Cosmetics
Applied in lotions, skincare products, creams, and hygienic process water preparation.
Food & Beverage
Suitable for ingredient preparation and clean production process water systems.
Electronics
Can be integrated with polishing systems for high-purity process water applications.
Production Process
The following flow chart shows a typical process route for a pharma water generation system with EDI polishing unit.
Optional Configurations
- Double Pass RO System
- High Recovery RO Design
- Ozone Sanitization System
- UV Sterilization Module
- Hot Water Sanitization
- Online TOC Monitoring
- Conductivity Monitoring
- Automatic CIP System
- SS316L Electropolished Piping
- Heat Exchanger
- Remote Monitoring System
- Automatic Control Cabinet
- Modular Containerized Structure
- Distribution Circulation Loop
- Pasteurization System
Why Choose CHONGYANG WATER
CHONGYANG WATER is a professional manufacturer specializing in purified water generation systems, EDI polishing solutions, and clean utility engineering equipment.
With extensive project experience in biotechnology, healthcare, laboratory, cosmetics, and industrial water treatment industries, we provide reliable turnkey engineering solutions for global customers.
- Professional water engineering team
- Extensive EDI system experience
- Hygienic engineering design
- Customized turnkey solutions
- FAT / SAT support
- Installation and commissioning service
- Technical training and after-sales support
