Ro Water Purifier Machine Ro Plant In Industry Polyamide Composite Membrane
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-RO-10000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 4999-10000 KGS |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 Sets/Month |
|
Detail Information |
|||
| Product Name: | Water Purification Devices | Capacity: | 100LPH-10000LPH |
|---|---|---|---|
| RO Membrane: | DOW, HYDRANAUTICS | Raw Water Quality: | ≤400 Ppm |
| Filter Core Size: | 0.22μm,1μm,5μm | Water Source: | Tap Water, Underground, |
| Water Tank Material: | Stainless Steel ,FRP | Valve: | Butterfly Valve ,Ball Valve |
| Filter Material: | Sand,Activated Carbon ,Resin | Raw Water Pump: | Grundfos ,CNP |
| Highlight: | Polyamide Composite Membrane RO Plant,Underground ro water purifier machine,industrial FRP ro plant |
||
Product Description
Product Name: Polyamide Composite Membrane Purified Water System Underground Water RO Water Machine
What is the polyamide composite membrane ?
A polyamide composite membrane purified water system is a type of reverse osmosis (RO) water treatment system that is designed to produce purified water from underground water sources. The system uses a polyamide composite membrane, which is a type of thin-film composite (TFC) membrane that is commonly used in industrial RO applications.
The system typically includes a pre-treatment stage, which removes larger particles and impurities from the feed water before it enters the RO membrane. The pre-treatment may include processes such as sediment filtration, activated carbon filtration, and pH adjustment.
The RO membrane is the heart of the system, and it works by using pressure to force water through the semipermeable membrane, which removes dissolved solids and other impurities from the water. The purified water that passes through the membrane is collected in a permeate tank, while the remaining impurities and concentrate are discharged or sent to a brine tank for further treatment.
The Partial Product Specification:
| Type |
Capacity (M3/H) |
Pipe DN (mm) |
WP (MPa) |
Material |
Work Method |
| CY-RO-0.25 | 0.25 | DN20 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-0.5 | 0.5 | DN20 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-1 | 1 | DN25 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-2 | 2 | DN32 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-3 | 3 | DN40 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-5 | 5 | DN50 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-8 | 8 | DN65 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-10 | 10 | DN80 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-15 | 15 | DN100 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-20 | 20 | DN100 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-30 | 30 | DN125 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-40 | 40 | DN150 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-50 | 50 | DN200 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
FAQ:
1.Question:Can you customize various capacity for us ?
Answer:Yes. We can customize for you .
2. Question: What is the raw water quality ?
Answer: Tap water, Underground Water ,it is better to be water quality that under TDS 400 PPM.
3.Question:How to install the big project of water treatment equipment ?
Answer : CHONGYANG Provide turnkey projects .
4. Question: How long is the warranty period ?
Answer: 1 year.
5. Question:How to settle water equipment's faults ?
Answer :CHONGYANG WATER can provide remotely repair for software , Change new parts without fee for hardware if it is till during guarantee period .
