UPVC Commercial Water Purifier Plant Ro Plant In Industry Electronic
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-RO-10000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 4999-10000 KGS |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 Sets/Month |
|
Detail Information |
|||
| Product Name: | Water Purification Devices | Capacity: | 100LPH-10000LPH |
|---|---|---|---|
| RO Membrane: | DOW, HYDRANAUTICS | Raw Water Quality: | ≤400 Ppm |
| Filter Core Size: | 0.22μm,1μm,5μm | Water Source: | Tap Water, Underground, |
| Water Tank Material: | Stainless Steel ,FRP | Valve: | Butterfly Valve ,Ball Valve |
| Filter Material: | Sand,Activated Carbon ,Resin | Pump: | Grundfos ,CNP |
| Highlight: | Electronic Ro Plant In Industry,UPVC ro plant in industry,FRP commercial water purifier plant |
||
Product Description
Product Name: UPVC RO Water Treatment System for Electronic Industry
A double pass RO water filter plant is a two-stage RO system that is designed to produce ultra-pure water with a very low level of impurities. The first stage of the system removes larger particles and impurities from the feed water, while the second stage uses a high-rejection RO membrane to remove dissolved solids and other impurities from the water.
In an electroplating double pass RO water filter plant, the second stage of the system is often followed by a mixed-bed ion exchange resin, which further removes any remaining ions that were not removed by the RO membrane. The mixed-bed resin contains both cation and anion exchange resins, which work together to remove all remaining ions and produce ultra-pure water.
The purified water produced by the double pass RO water filter plant is typically stored in a dedicated tank and then fed directly to the electroplating process. The high-purity water produced by the system ensures that the electroplating process is consistent and that the final product is of high quality.
The Partial Product Specification:
| Type |
Capacity (M3/H) |
Pipe DN (mm) |
WP (MPa) |
Material |
Work Method |
| CY-RO-0.25 | 0.25 | DN20 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-0.5 | 0.5 | DN20 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-1 | 1 | DN25 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-2 | 2 | DN32 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-3 | 3 | DN40 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-5 | 5 | DN50 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-8 | 8 | DN65 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-10 | 10 | DN80 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-15 | 15 | DN100 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-20 | 20 | DN100 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-30 | 30 | DN125 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-40 | 40 | DN150 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-50 | 50 | DN200 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
FAQ:
1.Question:Can you customize various capacity for us ?
Answer:Yes. We can customize for you .
2. Question: What is the raw water quality ?
Answer: Tap water, Underground Water ,it is better to be water quality that under TDS 400 PPM.
3.Question:How to install the big project of water treatment equipment ?
Answer : CHONGYANG Provide turnkey projects .
4. Question: How long is the warranty period ?
Answer: 1 year.
5. Question:How to settle water equipment's faults ?
Answer :CHONGYANG WATER can provide remotely repair for software , Change new parts without fee for hardware if it is till during guarantee period .
