Industrial PSG Pure Steam Generation System Pharmaceutical Plant Steam Production
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-PS-100KGS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Supply Ability: | 100 Sets/Month |
|
Detail Information |
|||
| Useful: | Disinfection & Sterilization | Material: | SS316L |
|---|---|---|---|
| Capacity: | 100KGS-10000KGS | Hot Source: | Industrial Steam |
| Product Name: | Clean Steam Generators | Control Method: | PLC+HIM SIEMENS |
| Highlight: | Industrial Sterilization Pure Steam Generator,PSG Pure Steam Generation System,Disinfection Steam Generation System |
||
Product Description
Product Name:Pharmaceutical-grade pure steam for for the sterilization of pharmaceutical equipment and product sterilization
Pure Steam Generator is used for Sterilizing systems,Moistening air,Sterilizing products used in sterilization
Chongyang Manufactures Pure Steam Generators to meet cGMP requirements. Condensate of this produced pure steam meets all pharmacopoeia requirements of WFI like USP, IP, BP and JP. The plant is manufactured as per FDA current Good Manufacturing Practices (cGMP) and ASME requirements.
Pure Steam generated from this equipment also surpasses steam quality tests like non-condensable gases, degree of super heat and saturation test as per requirement.
It must meet the basic following physical properties.
Non-Condensable gases < 3.5%
Dryness Value >0.9%
Super Heat Value <25oC
CHONGYANG Water Spec. & Type
| Type | Capacity | Feed Water | Industry Steam | Height(mm) | Length(mm) | Wide(mm) |
| PS100 | 100 | 115 | 130 | 2100 | 900 | 570 |
| PS200 | 200 | 230 | 250 | 2500 | 900 | 570 |
| PS300 | 300 | 345 | 370 | 2500 | 1100 | 680 |
| PS400 | 400 | 460 | 480 | 2600 | 1100 | 680 |
| PS500 | 500 | 575 | 173 | 2600 | 1170 | 720 |
| PS800 | 800 | 920 | 960 | 3500 | 1775 | 930 |
| PS1000 | 1000 | 1150 | 1200 | 3700 | 1775 | 930 |
| PS2000 | 2000 | 2300 | 2400 | 4000 | 2030 | 1900 |
| PS3000 | 3000 | 3450 | 3600 | 4850 | 2030 | 1900 |
| PS4000 | 4000 | 4600 | 4800 | 5100 | 2200 |
2100 |
FAQ:
1.Question:Can you customize various capacity for us ?
Answer:Yes. We can customize for you .
2. Question: What is the raw water quality ?
Answer: Tap water, Underground Water ,it is better to be water quality that under TDS 400 PPM.
3.Question:How to install the big project of water treatment equipment ?
Answer : CHONGYANG Provide turnkey projects .
4. Question: How long is the warranty period ?
Answer: 1 year.
5. Question:How to settle water equipment's faults ?
Answer :CHONGYANG WATER can provide remotely repair for software , Change new parts without fee for hardware if it is till during guarantee period .
