Reverse Osmosis Water Filter System Municipal Drinking Water Treatment
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-RO-10000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Sets/Month |
|
Detail Information |
|||
| Equipment Name: | Reverse Osmosis System | Filter Material: | FRP |
|---|---|---|---|
| Process: | Pre-treatment+ Double RO System | Touch Screen: | SIEMENS |
| RO Brand: | DOW ,HYDRANAUTICS | Control Method: | SEIMENS PLC+HIM |
| Pump Brand: | Grundfos , CNP | Flowmeter: | KROHNE |
| Conductivity: | 1-5 μS/cm | Pressure: | Less Than 0.3Mpa |
| Highlight: | Municipal Reverse Osmosis Water Filter System,FRP Reverse Osmosis Water Filter System,Reverse Osmosis Municipal Drinking Water Treatment |
||
Product Description
Product Name:Full Stainless Steel Food And Beverage Water Treatment RO Mineral Water Purification Plant
What is the configuration of reverse osmosis system :
The configuration of a reverse osmosis (RO) system can vary depending on the specific application and requirements, but the basic components typically include:
Pre-filtration stage: In this stage, the water is passed through one or more pre-filters to remove large particles, sediment, and other contaminants that could damage the RO membrane.
High-pressure pump: The pre-filtered water is then pressurized by a high-pressure pump to force it through the RO membrane.
Reverse osmosis membrane: The heart of the RO system is the semi-permeable membrane, which allows water molecules to pass through while rejecting dissolved salts, minerals, and other contaminants.
Post-filtration stage: After passing through the RO membrane, the water may be subjected to additional filtration to remove any remaining particles or contaminants.
Storage tank: The purified water is stored in a tank until it is needed.
Delivery system: A faucet or other delivery system is used to dispense the purified water.
In addition to these basic components, an RO system may also include various sensors, monitors, and control systems to ensure optimal performance and monitor water quality.
The Partial Product Specification:
| Type |
Capacity (M3/H) |
Pipe DN (mm) |
WP (MPa) |
Material | Work Method |
| CY-RO-0.25 | 0.25 | DN20 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-0.5 | 0.5 | DN20 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-1 | 1 | DN25 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-2 | 2 | DN32 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-3 | 3 | DN40 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-5 | 5 | DN50 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-10 | 10 | DN75 | ≤1.0 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-20 | 20 | DN100 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-30 | 30 | DN125 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-40 | 40 | DN150 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
| CY-RO-50 | 50 | DN200 | ≤1.6 | Stainless Steel/Carbon Steel | Full Auto/Semi Automatic |
FAQ:
1.Question:How often should I replace the filters in a reverse osmosis system?
Answer:As a general guideline, it's recommended that the pre-filter and post-filter be replaced every 3-6 months.
2.Question:How to maintain the big capacity Reverse Osmosis System ?
Answer: 1.Regularly check the system for leaks 2.Monitor water pressure 3.Inspect and clean the pre-filters.
3.Question: How to install RO Plant?
Answer:Install the RO system equipment, including pre-filters, pumps, membranes, and post-filters, according to the manufacturer's instructions and any applicable regulations,we can provide video by wechat ,whatsapp number on-line .
4.Question: Where is the CHONGYANG Water located ?
Answer: SHANGHAI ,JIANGSU
