WFI Dm Water Storage Tank Pharmaceutical Storage Tank
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO |
| Model Number: | CY-WT-500L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 20 Sets/Month |
|
Detail Information |
|||
| Product Name: | Water For Injection Tank | Material: | SS316 |
|---|---|---|---|
| Volume: | 300L-20,000L | Layer: | Three |
| Port Location: | Top, Bottom, | Polishing: | 0.6 Ra |
| Application: | Water For Injection,Pure Water ,Purified Water | Liquid Level Location: | Bottom |
| Highlight: | WFI dm water storage tank,Pharmaceutical Dm Water Storage Tank,Stainless Steel Pharmaceutical Storage Tank |
||
Product Description
Product Name:Water For Injection (WFI) Tank Pharmaceutical Storage Water Tanks
What is the Water For Injection Tank ?
Water for Injection (WFI) tanks are specialized tanks that are used to store and distribute high-purity water that is used in the production of pharmaceuticals. WFI is water that has been purified to meet the specifications of the United States Pharmacopeia (USP) for use in pharmaceuticals.
The materials used to make WFI tanks are typically chosen for their ability to maintain the purity of the water. Some common materials used to make WFI tanks include:
Stainless steel: Stainless steel is a popular choice for WFI tanks because it is highly resistant to corrosion and can be easily sanitized.
Polypropylene: Polypropylene is a plastic material that is highly resistant to chemicals and can be easily cleaned and sterilized.
Glass-lined steel: Glass-lined steel tanks are made by coating steel with a layer of glass. This creates a tank that is both strong and corrosion-resistant, while also being easy to clean.
In addition to the materials used to make the tank, WFI tanks may also include specialized features such as ultra-filtration systems, distillation units, and monitoring systems to ensure that the water meets the required standards for purity and quality.
The size of WFI tanks can vary depending on the specific needs of the application. However, common sizes for WFI tanks range from 1000 liters (264 gallons) to 10,000 liters (2,640 gallons). The size of the tank will depend on factors such as the volume of water required for the specific application, the space available for the tank, and the budget for the project. It's important to choose a tank size that can meet the requirements of the application while also being practical in terms of installation, maintenance, and cost.
|
Volume (L) |
Diameter (mm) |
Height (mm) |
Total Height (mm) |
Manhole (mm) |
| 300 | 500 | 1220 | 1720 | 200 |
| 500 | 800 | 1000 | 1890 | 350 |
| 1000 | 800 | 1500 | 2390 | 350 |
| 1000 | 1000 | 1000 | 2005 | 350 |
| 1000 | 1100 | 900 | 1920 | 350 |
| 1500 | 1300 | 1000 | 2180 | 400 |
| 2000 | 1000 | 2000 | 2960 | 400 |
| 2000 | 1300 | 1300 | 2530 | 400 |
| 3000 | 1500 | 1500 | 2920 | 400 |
| 5000 | 1800 | 1800 | 3220 | 400 |
| 5000 | 1700 | 2000 | 3420 | 400 |
| 6000 | 1700 | 2440 | 3860 | 400 |
| 10000 | 2100 | 2500 | 3220 | 400 |
| 15000 | 2600 | 2500 | 4380 | 400 |
FAQ:
1.Question:Can you customize various capacity for us ?
Answer:Yes. We can customize for you .
2. Question: What is the raw water quality ?
Answer: Tap water, Underground Water ,it is better to be water quality that under TDS 400 PPM.
3.Question:How to install the big project of water treatment equipment ?
Answer : CHONGYANG Provide turnkey projects .
4. Question: How long is the warranty period ?
Answer: 1 year.
5. Question:How to settle water equipment's faults ?
Answer :CHONGYANG WATER can provide remotely repair for software , Change new parts without fee for hardware if it is till during guarantee period .
